Linux Touch Panel by Raspberry PI CM5 | Cost-effective & Flexible

product01
Tech-Spec Get a quote
Model Name: AT1080

Linux Touch Panel by Raspberry PI CM5, A Balance Of Flexible customization & Cost-Effectiveness

>Flexibility & Customization

Ideal for businesses looking for tailor-made industrial solutions, no worry for NRE & inventor;

>Cost-Effectiveness

Great for small projects that need to minimize costs while still leveraging cutting-edge technology;

>Open Source & Strong Community

With an active community and broad ecosystem support, customers have access to plenty of resources, libraries, and 3rd-party add-ons.



Features

Compute Module 5 is a powerful and scalable system on module with a 64‐bit Arm processor @ 2.4GHz, it’s also an I/O controller, video and PCIe interfaces, and a range of wireless, SDRAM and eMMC options.

Developers can leverage its efficient software stack in their own embedded systems, with our I/O extension board and expertise in LCD screen & touch panel, they can quickly have their ready to ship smart hardware, manageable, scalable and fully under their own control.

Linux Touch Panel Board Layout

Specification

Processor: Broadcom BCM2712 quad‐core 64‐bit Arm Cortex‐

A76 (Armv8) SoC @ 2.4GHz;

Memory Options: 2GB, 4GB, 8GB, or 16GB LPDDR4‐4267

SDRAM with ECC; 0GB, 16GB, 32GB or 64GB eMMC flash.

Screen size : 10.1” (Diagonal)

Active area : 216.96(H) x 135.6(V)

Max. Resolution : 1280 (H) x 800 (V)

Brightness : 350 cd/m2

Contrast ratio : 1000 : 1

Viewing angle : 89/89/89/89(L/R/U/D)

Aspect Ratio: 16:10

Interface: >2x USB 2.0 ;

>Phoenix GPIO (4‐pin bi‐directional terminal block) ;

>Micro SD Card Slot x1 ;

>HDMI Out 2.0 x1;

>USB 3.0 Type‐C x1 ;

>Ethernet 1000M /100M RJ45x1 ;

>DC 5.5/2.1 12V Power In ;

>Optional: Power over Ethernet

> Reset button x1;
